Introduction to Modeling

Starting Your Final Projects

Upcoming Tasks / Deadlines

Form a group of up to 3 students
Find a dataset
Form some research questions
Do some preliminary explorations of the data
Write up your project proposal

Tip

The Final Project instructions page has suggestions for where to find datasets.

Project Proposal - Due Sunday, February 23

Your group member names.
Information about the dataset(s) you intend to analyze:
- Where are the data located?
- Who collected the data and why?
- What information (variables) are in the dataset?
Research Questions: You should have one primary research question and a few secondary questions
Preliminary exploration of your dataset(s): A few simple plots or summary statistics that relate to the variables you plan to study.

The story so far…

Steps for Data Analysis

Read and then clean the data
- Are there missing values? Will we drop those rows, or replace the missing values with something?
- Are there quantitative variables that Python thinks are categorical?
- Are there categorical variables that Python thinks are quantitative?
- Are there any anomalies in the data that concern you?

Steps for Data Analysis (cont’d)

Explore the data by visualizing and summarizing.
- Different approaches for different combos of quantitative and categorical variables
- Think about conditional calculations (split-apply-combine)

Steps for Data Analysis (cont’d)

Identify a research question of interest.
Perform preprocessing steps
- Should we scale the quantitative variables?
- Should we one-hot-encode the categorical variables?
- Should we log-transform any variables?
Measure similarity between observations by calculating distances.
- Which features should be included?
- Which distance metric should we use?

Machine Learning and Statistical Modeling

Modeling

Every analysis we will do assumes a structure like:

(output) = f(input) + (noise)

… or, if you prefer…

target = f(predictors) + noise

Generative Process

In either case: we are trying to reconstruct information in data, and we are hindered by random noise.

The function \(f\) might be very simple…

\[y_i = \mu + \epsilon_i\]

“A person’s height is the true average height of people in the world, plus some randomness.”

Generative Process

… or more complex…

\[y_i = 0.5*x_{1i} + 0.5*x_{2i} + \epsilon_i\]

“A person’s height is equal to the average of their biological mother’s height and biological father’s height, plus some randomness”

Tip

Do you think there is “more randomness” in the first function or this one?

Generative Process

… or extremely, ridiculously complex…

Generative Process

… and it doesn’t have to be a mathematical function at all!

The process can just a procedure:

\[y_i = \text{(average of heights of 5 people with most similar weights)} + \epsilon_i\]

Modeling

Our goal is to reconstruct or estimate or approximate the function / process \(f\) based on training data.
- For example: Instead of the 5 most similar weights in the whole world, we can estimate with the 5 most similar weights in our training set.
Instead of committing to one \(f\) to estimate, we might propose many options and see which one “leaves behind” the least randomness (has the smallest errors).

Data: Wine Price Prediction

Setup

import pandas as pd
from sklearn.compose import make_column_transformer
from sklearn.preprocessing import OneHotEncoder
from sklearn.preprocessing import StandardScaler

df = pd.read_csv("https://dlsun.github.io/pods/data/bordeaux.csv")

Training Data

known = df["year"] < 1981
df_train = df[known]

Testing Data

unknown = df["year"] > 1980
df_test = df[unknown]

KNN Revisited

Column Transformer

from sklearn.pipeline import make_pipeline
from sklearn.neighbors import KNeighborsRegressor

features = ['summer', 'har', 'sep', 'win', 'age']

ct = make_column_transformer(
  (StandardScaler(), features),
  remainder = "drop"
)

Pipeline

pipeline = make_pipeline(
  ct,
  KNeighborsRegressor(n_neighbors = 5)
  )

KNN Revisited

Fit

pipeline.fit(X = df_train,
             y = df_train['price'])

Pipeline(steps=[('columntransformer',
                 ColumnTransformer(transformers=[('standardscaler',
                                                  StandardScaler(),
                                                  ['summer', 'har', 'sep',
                                                   'win', 'age'])])),
                ('kneighborsregressor', KNeighborsRegressor())])

In a Jupyter environment, please rerun this cell to show the HTML representation or trust the notebook.
On GitHub, the HTML representation is unable to render, please try loading this page with nbviewer.org.

KNN Revisited

Predict

pred_y_train = pipeline.predict(X = df_test)

Measuring Error

The most common way to measure “leftover noise” is the sum of squared error or equivalently, the mean squared error.

pred_y_train = pipeline.predict(X = df_train)

results = pd.DataFrame({
  "real_prices": df_train['price'],
  "predicted_prices": pred_y_train,
})
results["squared error"] = (results["predicted_prices"] - results["real_prices"])**2
results

    real_prices  predicted_prices  squared error
0          37.0              36.2           0.64
1          63.0              41.4         466.56
2          45.0              46.6           2.56
3          22.0              28.8          46.24
4          18.0              46.4         806.56
5          66.0              35.2         948.64
6          14.0              13.0           1.00
7         100.0              56.6        1883.56
8          33.0              40.4          54.76
9          17.0              16.0           1.00
10         31.0              37.0          36.00
11         11.0              12.2           1.44
12         47.0              32.0         225.00
13         19.0              26.0          49.00
14         11.0              11.8           0.64
15         12.0              18.2          38.44
16         40.0              29.8         104.04
17         27.0              24.8           4.84
18         10.0              13.6          12.96
19         16.0              28.8         163.84
20         11.0              19.8          77.44
21         30.0              24.0          36.00
22         25.0              18.8          38.44
23         11.0              25.0         196.00
24         27.0              18.4          73.96
25         21.0              18.4           6.76
26         14.0              25.8         139.24

Measuring Error

The most common way to measure “leftover noise” is the sum of squared error or equivalently, the mean squared error.

results["squared error"].mean()

np.float64(200.57629629629628)

Best K

Now let’s try it for some different values of \(k\)

for k in [1, 3, 5, 10, 25]:
  pipeline = make_pipeline(
    ct,
    KNeighborsRegressor(n_neighbors = k)
    )
  pipeline = pipeline.fit(X = df_train, y = df_train['price'])
  pred_y_train = pipeline.predict(X = df_train)
  ((df_train['price'] - pred_y_train)**2).mean()

np.float64(0.0)
np.float64(123.2304526748971)
np.float64(200.57629629629628)
np.float64(241.37518518518516)
np.float64(378.9575703703703)

Training Error Versus Test Error

Oh no! Why did we get an error of 0 for \(k = 1\)?
Because the closest wine in the training set is… itself.
So, our problem is:
- If we predict on the new data, we don’t know the true prices and we can’t evaluate our models.
- If we predict on the training data, we are “cheating,” because we are using the data to both train and test.
Solution: Let’s make a pretend test data set!

Another Test / Training Split

test = (df["year"] > 1970) & (df["year"] < 1981)
train = df["year"] < 1971

df_train_new = df[train].copy()
df_test_new = df[test].copy()

We will train on the years up to 1970
We will test on the years 1971 to 1980
We will evaluate based on model performance on the test data.

Try Again: Best K

for k in range(1,15):
  pipeline = make_pipeline(
    ct,
    KNeighborsRegressor(n_neighbors = k))

  pipeline = pipeline.fit(X = df_train_new,
                          y = df_train_new['price'])

  pred_y_test = pipeline.predict(X = df_test_new)

  print(str(k) + ":" + str(((df_test_new['price'] - pred_y_test)**2).mean()))

1:183.0
2:139.85
3:123.78888888888892
4:159.34375
5:121.81199999999998
6:83.28333333333333
7:86.08163265306123
8:86.465625
9:73.12839506172841
10:72.263
11:89.03801652892564
12:133.99791666666667
13:162.23136094674555
14:169.534693877551

Tuning

Here we tried the same type of model (KNN) each time.
But we tried different models because we used different values of \(k\).
This is called model tuning!

Activity

Perform tuning for a KNN model, but with all possible values of k.

Do this for three column transformers:

Using all predictors.
Using just winter rainfall and summer temperature.
Using only age.

Which of the many model options performed best?

Things to think about

What other types of models could we have tried?
- Linear regression, decision tree, neural network, …
What other column transformers could we have tried?
- Different combinations of variables, different standardizing, log transforming…
What other measures of error could we have tried?
- Mean absolute error, log-error, percent error, …
What if we had used a different test set?
- Coming soon: Cross-validation
What if our target variable was categorical?
- Logistic regression, multinomial regression, decision trees,…

Modeling: General Procedure

Modeling

For each model proposed:

Establish a pipeline with transformers and a model.
Fit the pipeline on the training data (with known outcome).
Predict with the fitted pipeline on test data (with known outcome).
Evaluate our success (i.e., measure noise “left over”).

Then:

Select the best model.
Fit on all the data.
Predict on any future data (with unknown outcome).

Big decisions

Which models to try
Which column transformers to try
How much to tune
How to measure the “success” of a model
